Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machines. They make equipment such as manlifts, boom lifts and aerial lifts. These equipments are designed to facilitate access to places which are difficult to reach, large equipment, roofs and buildings, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains platforms, or steps or handholds which are connected to the unit to be able to transport personnel from every floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. In addition, the maximum height of the platform reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
